manufacturer :       Observator

model :                   OMC 388

annotation :           Dokumente engl.

The OMC-388 is shipped with Microsoft Windows® CE operating system loaded in the on-board Flash system memory. The main screen is the Microsoft Windows® CE Software Shell from which the windows browser can be opened along with other applications, which are loaded into the Instrument.

The OMC-388 PCMCIA interface can accept ATA Flash memory cards and can also accept any Type I or type II card that is supported with a Microsoft Windows® CE driver.

The OMC-388 can be powered from the internal (Li-lon) battery or from an external DC supply. The OMC-388 has an internal backup battery which maintains the system settings should the OMC-388's battery become discharged or be removed whilst the unit is not being powered from an external DC supply.

Spezification

Enclosure

Size                            186mm x 93ram at narrowest point

                                  186nan x 134mm at widest point

Weight                        <700g (1.5 lbs.)

Gase                          Material: 80% ABS and 20% Polycarbonate plastic

                                  Hand strap fixing an either side of unit

Display                       1/4 VGA : 65536 colour touch screen (240 x 320) TFT

Connector Panel

PC Comms                RS232 - 9 way D Type (Plug )
IrDA Window

                                  USB Client (1.5MB & 12MB)

I/O                              7 pin Fischer

Battery/Power

Battery                        Li-Ion Smart Battery Pack (rechargeahle)

Operating Time          Greater than 14 hours (unit idle)

Charging                    In the unit or via an external charger/docking station.

                                  Unit can he powered indelinitely via external DC supply

Performance

Processing

Operating System     Windows CE.NET v4.2

Processor Type         400Milz X-scale — Intel PXA255

                                  MediaQ 1188 graphics controller

OS Storage                Microsoft Windows CE.NET & applications 24Mbytes
Unformatted disk 40Mbyte

Internat RAM              0/S5 ≈ 24Mbytes

(SDRAM)                    Approximately 40Mbytes available for customer use.

PC Card support        PCMCIA Type I or Type II cards

                                  SDIO (for memoDi only)

Environmental

Certifitkation               CE

Sealing                       IP65

Drop test                    2 metres (MIL-STD-810)

Temperature Range Operating: -10 to +50°C

                                  Storage: -20 to +60°C

Humidity                     Operating: 93% Relative Humidity @ 50°C

                                  50% Relative Humidity @ 40°C

I/0 and Communications

Serial comms            RS-232 serial port; Up to 115k band

lnfrared                       IrDA interface, Up to 115k band

USB Client                 1.5MB & 12MB
