PCR Sprint Thermal Cycler

The PCR Sprint Thermal Cycler is ideal for users who want to perform small amounts of PCR's an a regular basis. Fast and efficient, the PCR Sprint has two choices of sample format: The 0.2ml block Option has space for twenty-four tubes and the 0.5m1 block Option has space for twenty tubes. If your requirements change, the block is interchangeable so you do not need to buy a new cycler!

Product Detail

The PCR Sprint Thermal Cycler remains the Instrument of choice for low throughput labs requiring sub-ambient thermal cycling. It is one of the most compact, tost effective, licensed PCR machines available. It employs robust peltier technology with heating rates up to 3°C/sec with excellent uniformity and accuracy. Supplied with a heated lid as standard for oil free Operation it is available with a choice of 0.2 ml x 24 well or 0.5 ml x 20 well block formats.

Features

n          Heating rates: up to 3°C/second

n          Accurate block performance

n          Absolute temperature control from 4-99°C

n          Excellent uniformity: better than ±0.5°C within fifteen seconds

n          Oil free Operation

n          Easy to use programming: directory program storage of up to sixty programs

n          0.2 ml x 24 well or 0.5 ml x 20 well block formats

n          Three temperature control modes:

n          Active tube control

n          Simulated tube control

n          Block control

n          PCR licensed

Block Performance

The PCR Sprint maximises the rate of sample heating and cooling whilst maintaining tight sample temperature

uniformity across the block. PCR performance is maximised by our temperature control modes.

Auto-Adjust Heated Lid

The auto-adjust heated lid enables the user to perform oil free thermal cycling without having to set the lid

height to suit the tube in use.

Block Options

The PCR Sprint has two block options: a 0.2 ml block, which has space for twenty-four reactions, and a 0.5 ml block,

which has space for twenty reactions.

User Friendly Software

The PCR Sprint uses our proven program interface, which allows even the most sophisticated programs to be created and stored with ease. Advanced edit features enable time and temperature increments and decrements to be programmed. Up to 60 programs can be stored under user defined names within six sub-directories. The sub-directory structure allows multiple users to store programs within their own storage space.

Specifications

Temperature Control               Active tube control

Available                                  Simulated tube control

                                               Block control

Block Temperature Range:     4°C - 99°C

Block Heating Rate :               Up to 3°C/sec

Block Cooling Rate :               Up to 2°C/sec

Block Uniformity :                    ± 0.5°C within 15

Display Resolution :                0.1°C

Maximum programmed

dwell time :                             9 hr 59 min 59 sec

Heated Lid

Temperature Range :             95°C - 120°C

* :                                             PCR Sprint performance rneasurements are traceable to the UK National Physical Laboratory, the equivalent of U.S.Nist and cornparable standards laboratories worldwide.

Replacement Block                 0.5 ml

Modules :                                 0.2 ml

Standard Accessories :         Tube thermistor fc 0.2 ml or 0.5 ml blocks

Dimensions:                            180 W x 300 D x 230 H (mm)

Weight :                                   7.5 kg

Power :                                    250 W

PROGRAMMING:

Number of programs :            60

Number of directories :          6

Maximum number of               5

Program Stages:

Maximum number of

Steps per stage:                      5

Auto restart facility:                  Yes

Pause facility:                          Yes

Temperature ramping:            Yes

Time increment/

Decrement:                             Yes

Program naming:                    Yes

Run “end time”

calculation:                              Yes
