Firma:                Thermo Electron

Modell:              AS 3000

Kommentar:      Dokumente engl.

•            Automated sample preparation

•            Micro-robotic Operation

•            120-vial capacity with random vial access

•            Re-use of calibration standards

•            PC-based control available

•            Numerous integrated options available

•            Optimum sensitivity and selectivity with Thermo Electron columns

AS 3000 – Variable-volume Injection Autosampler

The AS3000 provides outstanding performance and maximum flexibility in an LC sample processing system. The standard unit offers 120-vial capacity, multiple injection modes, random vial access, re-use of calibra­tion standards, and priority sampling.

Integrated Options

For applications flexibility, the AS1000 can be configured to include an integrated column oven and sample tray temperature control. The AS3000 and AS3500 can be purchased with integrated column oven, sample tray temperature control, or sample preparation accessories.

Column Oven

Provides complete control of the column and injector temperature for increased separation efficiency and reproducibility. Available on AS1000, AS3000, and AS3500 models.

Tray Temperature Control

Tray temperature control stabilizes temperatures, heats and cools samples, and minimizes the effects of ambient temperature fluctuations. The tray temperature control is completely self­contained; there are no external parts, connections, or water baths. Available on AS1000, AS3000, and AS3500 models.

Sample Preparation

Outstanding dilution performance, a unique vortex mixer and vial heater, and a flexible, easy-to-use sample preparation langvage provide unmatched sampling versatility and capabilities. Available on AS3000 and AS3500 models only.

PC-based Control Available

Remote programming is possible with Thermo Electron's chromatography data systems. Atlas` 2003 provides remote Instrument control of the autosamplers, making them pari of a fully integrated, PC-controlled system.

As with most other SpectraSYSTEM components, the AS-series atuosamplers utilize the SN4000 System Controller for communication with the Atlas PC-based chromatography data system.

Vial Capacity

120 vials: 105 vials with temperature­controlled trag

Variable Volume (AS3000 and AS3500)

Injection Precision

< 0.5% RSD @ 10 µL

Injection Volume

0.1-100 µL injections standard up to

1500 µL injections with larger loops and syringe

Sample Carryover

Typically < 0.01 % at 400 µL flush volume

Minimum Sample Volume

1 µL can be injected from 10 µL

Needle Height

Programmable in 0.1 mm increments

Column Oven (optional)

20-80°C in 1 °C increments, starting at 5°C above ambient

Tray Temperature Control (optional)

0-60 °C in 1 °C increments

(Typical sample temperature-. 4-50 °C)

Sample Preparation (optional)

Mixing/Heating

Single vial, air-driven vortex mixer/heater, settable in 1 'C increments from 30-100 °C

Dilution Precision

Typically < 1.0% RSD for a 1 /100 dilution (10 pL to 1 mL) for the combined dilution and injection

Dispensing Precision

Typically < 0.2% RSD for 1 mL dispensing from external solvent reservoir

Method Files

Protected in non-volatile memory

Communications

Remote Inputs

Pump Ready, Iniect Hold

Outputs

Pump Stop, Autosampler Ready, Gradient Start, Inject

4 timed event outputs RS-232C

Ambient Environment

10-40 °C, 5--95% relative humidity, non-condensing

Dimensions

37 x 41 x 51 cm (H x W x D)

Weight

16 kg standard; 24 kg with all options installed

Power Requirements

100/120/220/240VAC nominal; 80-450VAC,

depending on installed options; 50/60 Hz

Product Certification

TUV CUS

TUV CE Mark

FCC (EMI)
